FYH方形帶座軸承:UKF213、UKFX13、UKF313、UKF215、UKFX15、UKF315、UKF216、UKFX16、UKF316、UKF217、UKFX17、 UKF317軸承參數

上一個： FYH帶座軸承菱形座軸承：UCFLX10、UCFL310、UCFL211、UCFL311、UCFL212、UCFL312、UCFL216、UCFL313、UCFL214、UCFL314、UCFL215

下一個： FYH帶座軸承方形座:UCF213、UCFX13、UCF313、UCF214、UCFX14、UCF314、UCF215、UCFX15、UCF315、UCF216、UCFX16、UCF316等

產品詳情

產品評論(0)

組件型號	軸承座型號	軸承公稱型號	軸徑	L 尺寸	J 尺寸	軸承座固定螺栓
UKF313+HE2313X	F313	UK313	2-1/4 in	208 mm 8-3/16 in	166 mm 6-17/32 in	M20 3/4 in
UKF313+H2313X	F313	UK313	60 mm	208 mm 8-3/16 in	166 mm 6-17/32 in	M20 3/4 in
UKF313+HS2313X	F313	UK313	2-3/8 in	208 mm 8-3/16 in	166 mm 6-17/32 in	M20 3/4 in
UKF215+HE315X	F215	UK215	2-1/2 in	200 mm 7-7/8 in	159 mm 6-17/64 in	M16 5/8 in
UKF215+H315X	F215	UK215	65 mm	200 mm 7-7/8 in	159 mm 6-17/64 in	M16 5/8 in
UKFX15+HE2315X	FX15	UKX15	2-1/2 in	197 mm 7-3/4 in	152 mm 5-63/64 in	M20 3/4 in
UKFX15+H2315X	FX15	UKX15	65 mm	197 mm 7-3/4 in	152 mm 5-63/64 in	M20 3/4 in
UKF315+HE2315X	F315	UK315	2-1/2 in	236 mm 9-9/32 in	184 mm 7-1/4 in	M22 7/8 in
UKF315+H2315X	F315	UK315	65 mm	236 mm 9-9/32 in	184 mm 7-1/4 in	M22 7/8 in
UKF216+HE316X	F216	UK216	2-3/4 in	208 mm 8-3/16 in	165 mm 6-1/2 in	M20 3/4 in
UKF216+H316X	F216	UK216	70 mm	208 mm 8-3/16 in	165 mm 6-1/2 in	M20 3/4 in
UKFX16+HE2316X	FX16	UKX16	2-3/4 in	214 mm 8-7/16 in	171 mm 6-47/64 in	M20 3/4 in
UKFX16+H2316X	FX16	UKX16	70 mm	214 mm 8-7/16 in	171 mm 6-47/64 in	M20 3/4 in
UKF316+HE2316X	F316	UK316	2-3/4 in	250 mm 9-27/32 in	196 mm 7-23/32 in	M27 1 in
UKF316+H2316X	F316	UK316	70 mm	250 mm 9-27/32 in	196 mm 7-23/32 in	M27 1 in
UKF217+H317X	F217	UK217	75 mm	220 mm 8-21/32 in	175 mm 6-57/64 in	M20 3/4 in
UKF217+HE317X	F217	UK217	3 in	220 mm 8-21/32 in	175 mm 6-57/64 in	M20 3/4 in
UKFX17+H2317X	FX17	UKX17	75 mm	214 mm 8-7/16 in	171 mm 6-47/64 in	M20 3/4 in
UKFX17+HE2317X	FX17	UKX17	3 in	214 mm 8-7/16 in	171 mm 6-47/64 in	M20 3/4 in
UKF317+H2317X	F317	UK317	75 mm	260 mm 10-1/4 in	204 mm 8-1/32 in	M27 1 in

組件型號	軸承座型號	軸承公稱型號	軸徑	L 尺寸	J 尺寸	軸承座固定螺栓
UKF317+HE2317X	F317	UK317	3 in	260 mm 10-1/4 in	204 mm 8-1/32 in	M27 1 in
UKF218+H318X	F218	UK218	80 mm	235 mm 9-1/4 in	187 mm 7-23/64 in	M20 3/4 in
UKFX18+H2318X	FX18	UKX18	80 mm	214 mm 8-7/16 in	171 mm 6-47/64 in	M20 3/4 in
UKF318+H2318X	F318	UK318	80 mm	280 mm 11-1/32 in	216 mm 8-1/2 in	M30 1-1/8 in
UKF319+HE2319X	F319	UK319	3-1/4 in	290 mm 11-13/32 in	228 mm 8-31/32 in	M30 1-1/8 in
UKF319+H2319X	F319	UK319	85 mm	290 mm 11-13/32 in	228 mm 8-31/32 in	M30 1-1/8 in
UKFX20+HE2320X	FX20	UKX20	3-1/2 in	268 mm 10-9/16 in	211 mm 8-5/16 in	M27 1 in
UKFX20+H2320X	FX20	UKX20	90 mm	268 mm 10-9/16 in	211 mm 8-5/16 in	M27 1 in
UKF320+HE2320X	F320	UK320	3-1/2 in	310 mm 12-7/32 in	242 mm 9-17/32 in	M33 1-1/4 in
UKF320+H2320X	F320	UK320	90 mm	310 mm 12-7/32 in	242 mm 9-17/32 in	M33 1-1/4 in
UKF322+H2322X	F322	UK322	100 mm	340 mm 13-3/8 in	266 mm 10-15/32 in	M36 1-3/8 in
UKF322+HE2322X	F322	UK322	4 in	340 mm 13-3/8 in	266 mm 10-15/32 in	M36 1-3/8 in
UKF324+H2324	F324	UK324	110 mm	370 mm 14-9/16 in	290 mm 11-27/64 in	M36 1-3/8 in
UKF326+HE2326	F326	UK326	4-1/2 in	410 mm 16-5/32 in	320 mm 12-19/32 in	M36 1-3/8 in
UKF326+H2326	F326	UK326	115 mm	410 mm 16-5/32 in	320 mm 12-19/32 in	M36 1-3/8 in
UKF328+H2328	F328	UK328	125 mm	450 mm 17-23/32 in	350 mm 13-25/32 in	M36 1-3/8 in

　　如需要同等規格其它品牌軸承：日本NSK帶座軸承，日本ASAHI帶座軸承，日本NTN帶座軸承；可以聯系我司工作人員咨詢，電話：0512-66505543 0512-87666709。

帶座外球面軸承類型介紹

　　帶座外球面球軸承由兩面帶密封的外球面球軸承和鑄造的（或鋼板沖壓的）軸承座組成。外球面球軸承的內部結構與深溝球軸承相同，但此種軸承的內圈寬于外圈.外圈具有截球形外表面，與軸承座的凹球面相配能自動調心。通常此種軸承的內孔與軸之間有間隙，用頂絲，偏心套或緊定套將軸承內圈固定在軸上，并隨軸一起轉動。帶座軸承結構緊湊，裝卸方便，密封完善，適用于簡單支承，常用于采礦.冶金.農業.化工.紡織.印染.輸送機械等。
