FYH帶座軸承UCP213、UCPX13、UCP313、UCP214、UCPX14、UCP314、UCP215、UCPX15、UCP315、UCP216、UCPX16、UCP316、UCP217等參數

上一個： FYH帶座軸承:UKP213、UKPX13、UKP313、UKP214、UKPX14、UKP314、UKP215、UKPX15、UKP315、UKP216、UKPX16、UKP316、UKP217

產品詳情

產品評論(0)

組件型號	軸承座型號	軸承公稱型號	軸徑	H 尺寸	L 尺寸	J 尺寸
UCPX11-35	PX11	UCX11-35	2-3/16 in	69.8 mm 2-3/4 in	260 mm 10-1/4 in	184 mm 7-1/4 in
UCPX11-36	PX11	UCX11-36	2-1/4 in	69.8 mm 2-3/4 in	260 mm 10-1/4 in	184 mm 7-1/4 in
UCP311-32	P311	UC311-32	2 in	80 mm 3-5/32 in	310 mm 12-7/32 in	236 mm 9-9/32 in
UCP311	P311	UC311	55 mm	80 mm 3-5/32 in	310 mm 12-7/32 in	236 mm 9-9/32 in
UCP311-35	P311	UC311-35	2-3/16 in	80 mm 3-5/32 in	310 mm 12-7/32 in	236 mm 9-9/32 in
UCP212-36	P212	UC212-36	2-1/4 in	69.8 mm 2-3/4 in	241 mm 9-1/2 in	184 mm 7-1/4 in
UCP212	P212	UC212	60 mm	69.8 mm 2-3/4 in	241 mm 9-1/2 in	184 mm 7-1/4 in
UCP212-38	P212	UC212-38	2-3/8 in	69.8 mm 2-3/4 in	241 mm 9-1/2 in	184 mm 7-1/4 in
UCP212-39	P212	UC212-39	2-7/16 in	69.8 mm 2-3/4 in	241 mm 9-1/2 in	184 mm 7-1/4 in
UCPX12	PX12	UCX12	60 mm	76.2 mm 3 in	286 mm 11-1/4 in	203 mm 8 in
UCPX12-39	PX12	UCX12-39	2-7/16 in	76.2 mm 3 in	286 mm 11-1/4 in	203 mm 8 in
UCP312	P312	UC312	60 mm	85 mm 3-11/32 in	330 mm 13 in	250 mm 9-27/32 in
UCP312-39	P312	UC312-39	2-7/16 in	85 mm 3-11/32 in	330 mm 13 in	250 mm 9-27/32 in
UCP213-40	P213	UC213-40	2-1/2 in	76.2 mm 3 in	265 mm 10-7/16 in	203 mm 8 in
UCP213	P213	UC213	65 mm	76.2 mm 3 in	265 mm 10-7/16 in	203 mm 8 in
UCPX13-40	PX13	UCX13-40	2-1/2 in	76.2 mm 3 in	286 mm 11-1/4 in	203 mm 8 in
UCPX13	PX13	UCX13	65 mm	76.2 mm 3 in	286 mm 11-1/4 in	203 mm 8 in
UCP313-40	P313	UC313-40	2-1/2 in	90 mm 3-35/64 in	340 mm 13-3/8 in	260 mm 10-1/4 in
UCP313	P313	UC313	65 mm	90 mm 3-35/64 in	340 mm 13-3/8 in	260 mm 10-1/4 in
UCP214-44	P214	UC214-44	2-3/4 in	79.4 mm 3-1/8 in	266 mm 10-15/32 in	210 mm 8-9/32 in

組件型號	軸承座型號	軸承公稱型號	軸徑	H 尺寸	L 尺寸	J 尺寸
UCP214	P214	UC214	70 mm	79.4 mm 3-1/8 in	266 mm 10-15/32 in	210 mm 8-9/32 in
UCPX14-44	PX14	UCX14-44	2-3/4 in	88.9 mm 3-1/2 in	330 mm 13 in	229 mm 9 in
UCPX14	PX14	UCX14	70 mm	88.9 mm 3-1/2 in	330 mm 13 in	229 mm 9 in
UCP314-44	P314	UC314-44	2-3/4 in	95 mm 3-47/64 in	360 mm 14-3/16 in	280 mm 11-1/32 in
UCP314	P314	UC314	70 mm	95 mm 3-47/64 in	360 mm 14-3/16 in	280 mm 11-1/32 in
UCP215-47	P215	UC215-47	2-15/16 in	82.6 mm 3-1/4 in	275 mm 10-13/16 in	217 mm 8-17/32 in
UCP215	P215	UC215	75 mm	82.6 mm 3-1/4 in	275 mm 10-13/16 in	217 mm 8-17/32 in
UCP215-48	P215	UC215-48	3 in	82.6 mm 3-1/4 in	275 mm 10-13/16 in	217 mm 8-17/32 in
UCPX15-47	PX15	UCX15-47	2-15/16 in	88.9 mm 3-1/2 in	330 mm 13 in	229 mm 9 in
UCPX15	PX15	UCX15	75 mm	88.9 mm 3-1/2 in	330 mm 13 in	229 mm 9 in
UCPX15-48	PX15	UCX15-48	3 in	88.9 mm 3-1/2 in	330 mm 13 in	229 mm 9 in
UCP315-47	P315	UC315-47	2-15/16 in	100 mm 3-15/16 in	380 mm 14-31/32 in	290 mm 11-13/32 in
UCP315	P315	UC315	75 mm	100 mm 3-15/16 in	380 mm 14-31/32 in	290 mm 11-13/32 in
UCP315-48	P315	UC315-48	3 in	100 mm 3-15/16 in	380 mm 14-31/32 in	290 mm 11-13/32 in
UCP216-50	P216	UC216-50	3-1/8 in	88.9 mm 3-1/2 in	292 mm 11-1/2 in	232 mm 9-1/8 in
UCP216	P216	UC216	80 mm	88.9 mm 3-1/2 in	292 mm 11-1/2 in	232 mm 9-1/8 in
UCPX16	PX16	UCX16	80 mm	101.6 mm 4 in	381 mm 15 in	283 mm 11-1/8 in
UCP316	P316	UC316	80 mm	106 mm 4-11/64 in	400 mm 15-3/4 in	300 mm 11-13/16 in
UCP217-52	P217	UC217-52	3-1/4 in	95.2 mm 3-3/4 in	310 mm 12-7/32 in	247 mm 9-23/32 in
UCP217	P217	UC217	85 mm	95.2 mm 3-3/4 in	310 mm 12-7/32 in	247 mm 9-23/32 in

組件型號	軸承座型號	軸承公稱型號	軸徑	H 尺寸	L 尺寸	J 尺寸
UCPX17	PX17	UCX17	85 mm	101.6 mm 4 in	381 mm 15 in	283 mm 11-1/8 in
UCPX17-55	PX17	UCX17-55	3-7/16 in	101.6 mm 4 in	381 mm 15 in	283 mm 11-1/8 in
UCP317	P317	UC317	85 mm	112 mm 4-13/32 in	420 mm 16-17/32 in	320 mm 12-19/32 in
UCP218-56	P218	UC218-56	3-1/2 in	101.6 mm 4 in	327 mm 12-7/8 in	262 mm 10-5/16 in
UCP218	P218	UC218	90 mm	101.6 mm 4 in	327 mm 12-7/8 in	262 mm 10-5/16 in
UCPX18	PX18	UCX18	90 mm	101.6 mm 4 in	381 mm 15 in	283 mm 11-1/8 in
UCP318-56	P318	UC318-56	3-1/2 in	118 mm 4-41/64 in	430 mm 16-15/16 in	330 mm 13 in
UCP318	P318	UC318	90 mm	118 mm 4-41/64 in	430 mm 16-15/16 in	330 mm 13 in
UCP319	P319	UC319	95 mm	125 mm 4-59/64 in	470 mm 18-1/2 in	360 mm 14-3/16 in
UCPX20	PX20	UCX20	100 mm	127 mm 5 in	432 mm 17 in	337 mm 13-1/4 in
UCPX20-63	PX20	UCX20-63	3-15/16 in	127 mm 5 in	432 mm 17 in	337 mm 13-1/4 in
UCPX20-64	PX20	UCX20-64	4 in	127 mm 5 in	432 mm 17 in	337 mm 13-1/4 in
UCP320	P320	UC320	100 mm	140 mm 5-33/64 in	490 mm 19-9/32 in	380 mm 14-31/32 in
UCP320-63	P320	UC320-63	3-15/16 in	140 mm 5-33/64 in	490 mm 19-9/32 in	380 mm 14-31/32 in
UCP320-64	P320	UC320-64	4 in	140 mm 5-33/64 in	490 mm 19-9/32 in	380 mm 14-31/32 in
UCP321	P321	UC321	105 mm	140 mm 5-33/64 in	490 mm 19-9/32 in	380 mm 14-31/32 in
UCP322	P322	UC322	110 mm	150 mm 5-29/32 in	520 mm 20-15/32 in	400 mm 15-3/4 in
UCP324	P324	UC324	120 mm	160 mm 6-19/64 in	570 mm 22-7/16 in	450 mm 17-23/32 in
UCP326	P326	UC326	130 mm	180 mm 7-3/32 in	600 mm 23-5/8 in	480 mm 18-29/32 in
UCP328	P328	UC328	140 mm	200 mm 7-7/8 in	620 mm 24-13/32 in	500 mm 19-11/16 in

　　如需要同等規格其它品牌軸承：日本NSK帶座軸承，日本ASAHI帶座軸承，日本NTN帶座軸承；可以聯系我司工作人員咨詢，電話：0512-66505543 0512-87666709。

帶座外球面軸承類型介紹

　　帶座外球面球軸承由兩面帶密封的外球面球軸承和鑄造的（或鋼板沖壓的）軸承座組成。外球面球軸承的內部結構與深溝球軸承相同，但此種軸承的內圈寬于外圈.外圈具有截球形外表面，與軸承座的凹球面相配能自動調心。通常此種軸承的內孔與軸之間有間隙，用頂絲，偏心套或緊定套將軸承內圈固定在軸上，并隨軸一起轉動。帶座軸承結構緊湊，裝卸方便，密封完善，適用于簡單支承，常用于采礦.冶金.農業.化工.紡織.印染.輸送機械等。
